Motor Potentiometers for Precision Control Applications

Motor potentiometers for precision control applications combine high-quality potentiometers with AC/DC motors to provide automated proportional controls. These devices offer exceptional precision, durability, and reliability for industrial automation, process control, and analog device automation with life expectancy ranging from 500,000 to 50 million turns.

Single turn Conductive plastic - 1 Watt - 50 ohm to 20K Standard - 1 3/8″ Dia x 3.76″L 5.5″L
Single turn wirewound - 0.5 Watt - 10 ohm to 20K - 1 3/8″ Dia x 3.76″L Dual 4.25″L
Single turn conductive plastic - 1 Watt - 500 ohm to 20K Standard - 1.5″ x 4 3/4″ L
Single turn conductive plastic - 1 Watt - 500 ohm to 20K Standard - 1.5″ x 5″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1.5″ x 5 1/4″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1 3/8″Dia x 4″ L
Single turn Conductive plastic - 1 Watt - 500 ohm to 100K - 1 1/4″Dia X 5.4″L
AC Motorized Potentiometers
10 turn wirewound - 5 Watt - 10 ohm to 100K - 2″ square x 8.5″ L
10 turn wirewound - 2 Watt - 5K/5K/5K normal. Others available. - 1 1/4″Dia x 7″ L
3 turn hybrid - 1 Watt - 1K to 100K - 7/8″Dia x 4 3/4″ L
Single turn wirewound - 0.5 Watt - 1K/1K, 2K/2K, 3K/3K, 5K/5K, 5K/10K, 10K/10K - 1.5″ x 5.25″ L
Single turn wirewound - 0.5 Watt - 10 ohm to 20K - 2″ x 5.25″ L
Single turn conductive plastic - 2 Watt - 500 ohm to 100K - 2″ square x 4 1/4″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - 7/8″ Dia x 4 3/4″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1 1/4″Dia x 4 3/4″ L
10 turn wirewound - 2 Watt - 1K/1K, 2K/2K, 5K/5K, 10K/10K, 2K/3K, 5K/10K - 1 1/4″Dia x 5 3/4″ L
10 turn wirewound - 5 Watt - 100 ohm to 100K Normal 1K - 2″ Square x 6 3/4″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1 1/4″Dia x 6″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - *
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1.5″ x 5″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1.5″ x 6 1/2″ L
Single turn conductive plastic - 2 Watt - 1K to 100K - 2″ square x 4″ L
Single turn wirewound - 0.5 Watt - 10 ohm to 20K - 1.5″ x 5″ L
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1.5″ x 6 3/4″ L
DC Motorized Potentiometer
10 turn wirewound - 2 Watt - 1K/1K, 2K/2K, 3K/3K, 5K/5K, 5K/10K, 10K/10K - 1.5″ x 6″ L

Our Range of Products
Single turn Conductive plastic - 1 Watt - 50 ohm to 20K Standard - 1 3/8″ Dia x 3.76″L 5.5″L

Single turn Conductive plastic - 1 Watt - 50 ohm to 20K Standard - 1 3/8″ Dia x 3.76″L 5.5″L

  • 10 million turns life expectancy
  • Gold plated terminals
  • Manual adjustment capability
Single turn wirewound - 0.5 Watt - 10 ohm to 20K - 1 3/8″ Dia x 3.76″L Dual 4.25″L

Single turn wirewound - 0.5 Watt - 10 ohm to 20K - 1 3/8″ Dia x 3.76″L Dual 4.25″L

  • Gold plated terminals
  • 500,000 turns life expectancy
  • Dual gang option available
Single turn conductive plastic - 1 Watt - 500 ohm to 20K Standard - 1.5″ x 4 3/4″ L

Single turn conductive plastic - 1 Watt - 500 ohm to 20K Standard - 1.5″ x 4 3/4″ L

  • 20 million turns life expectancy
  • Black anodized aluminum housing
  • AC motor with slip clutch
Single turn conductive plastic - 1 Watt - 500 ohm to 20K Standard - 1.5″ x 5″ L

Single turn conductive plastic - 1 Watt - 500 ohm to 20K Standard - 1.5″ x 5″ L

  • 20 million turns life expectancy
  • Circuit board with components
  • AC motor with slip clutch
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1.5″ x 5 1/4″ L

10 turn wirewound - 2 Watt - 100 ohm to 100K - 1.5″ x 5 1/4″ L

  • 1 million turns life expectancy
  • Circuit board with components
  • Manual adjustment capability
10 turn wirewound - 2 Watt - 100 ohm to 100K - 1 3/8″Dia x 4″ L

10 turn wirewound - 2 Watt - 100 ohm to 100K - 1 3/8″Dia x 4″ L

  • High temp thermo plastic housing
  • 1 million turns life expectancy
  • Manual adjustment when off

Showing 1 to 6 of 27 results

Frequently Asked Questions

What is the difference between wirewound and conductive plastic potentiometers?

Wirewound offers high precision and durability, while conductive plastic provides longer life (up to 50 million turns) and essentially infinite resolution.

What motor voltage options are available for these potentiometers?

How does the slip clutch protection work?

What is the typical life expectancy of these motor potentiometers?

Can these potentiometers be repaired or rebuilt?

What RPM options are available for the motors?

Are dual gang and triple gang configurations available?

Didn't find what you're looking for?

Talk to our experts for custom solutions and tailored guidance.

Industries We Serve

Industrial Automation

Industrial Automation

Precise motorized potentiometers provide automated control for manufacturing equipment and process systems.

Process Control

Process Control

High-precision control systems for flow meters, speed controls, and tensioning applications in production environments.

Aerospace & Defense

Aerospace & Defense

Reliable motorized potentiometers for aircraft, helicopter simulators, and military equipment requiring precise positioning.

Medical Equipment

Medical Equipment

High-precision motorized potentiometers ensuring accurate positioning and control in medical devices and equipment.

Didn't find what you're looking for?

Talk to our experts for custom solutions and tailored guidance.

You might also like

Single turn Conductive plastic - 1 Watt - 50 ohm to 20K Standard - 1 3/8″ Dia x 3.76″L 5.5″L | Motorized Potentiometers for Precision Speed Control

Motorized Potentiometers for Precision Speed Control

Motorized potentiometers for precision speed control combine high-quality potentiometer elements with reliable motor drives to provide accurate, automated positioning for analog control devices. These units feature slip clutch protection, long life expectancy, and are available in various configurations including AC/DC motors, wirewound/conductive plastic elements, and single/multi-turn designs for industrial automation applications.
AC Motorized Potentiometers | Rotary Potentiometer Position Sensors for Precision

Rotary Potentiometer Position Sensors for Precision

Rotary potentiometer position sensors combining precision potentiometers with motorized control for automated positioning and feedback applications. These high-precision devices integrate slip clutch protection, variable resistance values, and multiple motor configurations to deliver reliable proportional control in industrial automation, process control, and precision positioning systems.
AC Motorized Potentiometers | Servo Mount Potentiometers for Precision Control

Servo Mount Potentiometers for Precision Control

Servo mount potentiometers offer precise proportional control for automating analog-driven devices across industrial applications. These motorized units combine potentiometers with AC or DC motors, featuring slip clutch protection and multiple resistance options. Designed for long-term reliability with life expectancies ranging from 500,000 to 50 million turns.
